Lab Facility

The Automobile Department is well equipped with the following laboratory facilities.
1. Automotive Fuels and Lubricants Lab
2. Automotive Engine and Chassis Components lab
3. Two and Three Wheeler Lab
4. Automotive Electrical Laboratory
5. Automotive Engine Performance and Emission Testing lab
6. CAD Lab
7. Vehicle Maintenance and Reconditioning Lab
8. REC BOSCH Joint Certification Centre

Automotive Fuels and Lubricants Laboratory
The lab is equipped with all facilities to test fuel and lubricants as specified in the curriculum of Anna University. The following equipments are available:

• Saybolt Viscometer
• Redwood Viscometer
• Cleave land flash and fire point Apparatus
• Junkers gas calorimeter
• Bomb calorimeter
• Reid vapour pressure Apparatus
• ASTM Distillation Apparatus
• Penetrometer
• Drop point Apparatus
• Aniline Point Apparatus
• Carbon residue test Apparatus
• Copper strip corrosion test Apparatus
• Ash content determination Apparatus
• Cloud and pour point Apparatus

Automotive Engine and Chassis Components Lab
In the automotive engine components lab, students study the various engine components. The automotive chassis lab is equipped with heavy duty and light duty vehicles .The following components and systems are available for study:

• Heavy duty vehicle chassis frame
• Light duty vehicle chassis frame
• Multi cylinder petrol and diesel engines
• MPFI engine
• Petrol and Diesel fuel systems
• Different types of front axle and rear axle
• Differential unit
• Steering systems with different types of steering gear box
• Disc type and drum type hydraulic braking system
• Compressed air power braking systems
• Different types of clutch assemblies
• Different Gear Boxes
• Transfer case
• Suspension systems

Two and Three Wheeler Lab
The laboratory has various two wheelers and three wheelers to conduct all the tests specified in the curriculum of Anna University. The equipments available are:

• Two wheeler chassis dynamometer
• Two wheeler engines with transmission system
• Three wheeler with engine, chassis, and transmission system
• Shock absorber test Apparatus
• Coil spring test Apparatus
• Two wheeler with electronic fuel injection and Open ECU

Auto Electrical Laboratory
The department has well equipped Automotive Electrical Laboratory to facilitate the students to test the various components of Automobiles.
Equipments available:

• Starter and generator test bench
• Automotive electrical wiring setup
• Battery charger and battery testing equipment
• Ignition system test bench
• Spark plug testing and cleaning device
• General electrical test equipments

Automotive Engine Testing Lab
The Department has well established engine testing laboratory to carry out various performance and emission tests on Automotive Engines. The equipments available are:

• Multi-cylinder CI and SI engine cut-section models
• Single-cylinder CI and SI engine cut-section models
• Two wheeler engine test rig
• Multi cylinder SI test rig with hydraulic dynamometer
• Multi cylinder CI test rig with eddy current dynamometer
• Piezoelectric pick up & crank angle encoder
• 5 Gas analyzer for exhaust gas analysis
• Diesel Smoke Meter

CAD Lab
CAD/CAM facility caters to the training of our students in the usage of latest CAD and CAM software. The lab uses modelling software like AUTOCAD, PRO-E, CATIA, ANSYS and CAM software like EDGECAM, ESPRIT, DENFORD, and CNC TUTOR. CNC Trainer lathe and CNC milling trainer are also available. The offline simulation software certification courses are being run for students in PRO-E package by the in-house faculty. Desktop computers 35 Nos. of the following configuration:

Intel core i32100 processor / Intel H61 original board / 4 GB DDR3 RAM / 500 GB SATA HDD / 18.5’’ WTFT Monitors
This lab caters to the needs of the following labs:

II Year	Computer Aided Machine Drawing Laboratory
II Year	CAM Laboratory
III Year	Geometric Modelling of Automotive Components Laboratory
III Year	Computer Aided Vehicle Design Data Characteristics Laboratory
III Year	Mini Project
IV Year	Computer Aided Analysis laboratory
IV Year	Project Work

Vehicle Maintenance and Reconditioning Lab
The lab is equipped with the following equipments needed to study engine reconditioning and vehicle maintenance:

• Hyundai Santro Car, Ford Ecosport, Tata Indica Car and Maruti 800 Car
• FIP calibration apparatus
• Engine Analyzer
• Computerized Wheel Aligner
• Tyre remover
• Head light alignment gauge
• Cylinder re-boring machine
• Valve grinding and lapping machines
• Spark plug cleaner and tester
• Cylinder compression pressure gauge
• Vacuum gauge
• Cam angle and rpm tester
• Gas welding equipment

BOSCH LAB
A training lab for automotive testing is jointly set up in association with Bosch. Apart from the regular theory and practical sessions, our students gain exposure and hands-on with the recent technologies The BOSCH lab is facilitated with the following list of equipments

• FSA 740 Engine and Vehicle Analyzer
• Fuel Injection Pump Calibration
• ACS 650 – Air-Conditioning system
• Automotive Electrical test bench
• CRDi and MPFi Engine test rig

Research and Computing facilities
The department has a high end computing facility with 32 GB RAM for carrying out simulation related research projects by students and faculty members.
Fuel oxidation stability tester fully capable of testing automotive fuels according to international standards is available for R&D development in the area of alternative and biofuels

REC-BOSCH Joint Certification Centre
A training lab for automotive testing is jointly set up in association with Bosch. Apart from the regular theory and practical sessions, our students gain exposure and hands-on with the recent technologies like:

• Fuel Injection Pumps
• Auto Electrical
• Engine Diagnostic system
• Vehicle Diagnostic system

The BOSCH lab is facilitated with the following list of equipment

• FSA 740 Engine and Vehicle Analyzer
• Fuel Injection Pump Calibration
• ACS 650 – Air-Conditioning system
• Automotive Electrical test bench
• KTS 560 Scanner
• Nozzle tester
• Battery tester
• CRDi and MPFi Engine test rig
• Required accessories like fuel injection pump, starter motor, alternator, etc.

  FORD INDIA Company donated the FORD Eco Sports GDI Car to disseminate the knowledge on advanced automotive systems to AUTO, MECH and MCT students
• GDI Engine
• Modern Automotive Electronics
• Fault diagnosis
