Centre of Excellence for High Speed Jet Lab
The High Speed Jet Facility started in the year 2012 -13 with a seed money of Rs.12.5 L.The High Speed Laboratory provides facilities in the areas of High Speed Jet Mixing and Acoustics, Supersonic. Combustion and so on. In addition to catering to the needs of undergraduate laboratory course needs, it caters to the research requirements of a large number of Doctoral (PhD) and Master (MTech) students.The lab is equipped with an indigenously built Jet Acoustic Chamber.
Research Activities
| SI.No. | Lab Name | Brief Description | Equipments Details |
|---|---|---|---|
| 1 | Aircraft Structures Lab | Aim: To study the different load acting on the structure | Apparatus:Polariscope Setup, Forced Vibration Setup, Open Channel Section, Unsymmetrical Bending Section, Combined Loading in Circular Hollow Tube, Column Setup,Beams with Simply Supported and Cantilever end conditions, Drop Impact test setup, Bullet Impact test setup |
| 2 | Jet Propulsion Lab | Aim: To study the behavior and different properties of fluid flow through various ducts and engines. | Apparatus: Supersonic Jet Rig Setup (includes compressors, reservoir and settling chamber and pressure gauges), Pressure Regulating Valves, C-D nozzle models, Gang manometer, Pitot tube, Multi-Channel Pressure scanner, Flow Visualization setup, Aeroacoustic jet facility with microphone and DAS |
| 3 | Aero Engine Laboratory | Aim: To disassembly and carry out inspection on various engines components | Apparatus: Piston Engines (3 No), Jet Engines (3 No), Standard tools for dismantling and assembly |
| 4 | Aerodynamic Lab | Aim: To study the fluid flow behavior and properties around bluff and streamlined bodies. | Apparatus: Low-speed wind tunnel, Water table,Smoke flow visualization apparatus, Pitot-static tube, Pitot rake, Three-component force balance, Multi-tube manometer, Angle of attack modulator, Speed indicator, Airfoil, cylinder Test models,Hele Shaw Apparatus |
| 5 | Aircraft System Lab | Aim: To study different systems of aircraft | Apparatus:Serviceable aircraft with all above systems, Hydraulic Jacks (Screw Jack), Trestle adjustable, Spirit Level, Levelling Boards, Cable Tensiometer , Adjustable Spirit Level , Plumb Bob, Brake Torque Testing Rig, Filter Element clogging Test rig |
| 6 | Avionics Laboratory | Aim: To study various avionics system and their data transfer technique in aircraft | Apparatus:Microprocessor 8085 Kit, Adder/Subtractor Binary bits Kit, Encoder Kit, Decoder Kit, Multiplexer Kit, Demultiplexer Kit, Computers (4 Nos), Matlab software (2014), MILSTD 1553 |
| 7 | CAD/CAM and Simulation Laboratory | Aim: To study various designing and analysis software for aircraft design | Apparatus: 35 systems with CAD/CAM, CATIA V5R18 , ANSYS 12.1,AUTO CAD 2015, ,MATLAB R2014b, Edge CAM 10.5,Code_Saturne_4.0.1, ELMER 7.0-rev5884,Paraview_4.3.1,SALOME-7.5.1 and FANUC software, |
| 8 | Airframe Repair Laboratory | Aim: To give training on riveting, patchwork, welding ,carpentry and NDT | Apparatus: Shear cutter pedestal type, Drilling Machine, Bench Vices, Radius Bend bars, Pipe Flaring Tools, Welding machine, Glass fibre, epoxy resin, Strain gauges and strain indicator |
